Vinculin Antibody

• Catalog Number: orb699580
• Category: Antibodies
• Description: This antibody recognizes both Vinculin (125kDa) and meta-Vinculin (135kDa). Focal adhesions are identified as areas within the plasma membrane of tissue culture cells that adhere tightly to the underlying substrate. In vivo, these regions are involved in the adhesion of cells to the extracellular matrix. Paxillin and vinculin are cytoskeletal, focal adhesion proteins that are components of a protein complex which links the Actin network to the plasma membrane. Vinculin binding sites have been identified on other cytoskeletal proteins, including Talin and -Actinin has been shown to link Actin to integrins in the plasma membrane through interactions with the vinculin and Talin complex or by a direct interaction with integrin.
• Species/Host: Mouse
• Clonality: Monoclonal
• Clone Number: VCL/3617
• Tested applications: FACS, IF, IHC-P
• Reactivity: Human
• Isotype: Mouse IgG1, kappa
• Immunogen: Recombinant full-length human Vinculin protein was used as the immunogen for the Vinculin antibody.
• Antibody Type: Primary Antibody
• Dilution range: Immunofluorescence: 1-2ug/ml,Flow cytometry: 1-2ug/million cells,Immunohistochemistry (FFPE): 1-2ug/ml for 30 minutes at RT
• Purity: Protein G affinity chromatography
• Conjugation: Unconjugated
• Formula: 0.2 mg/ml in 1X PBS with 0.1 mg/ml BSA (US sourced), 0.05% sodium azide
• Hazard Information: This Vinculin antibody is available for research use only.
• UniProt ID: P18206
• Storage: Store the Vinculin antibody at 2-8°C (with azide) or aliquot and store at -20°C or colder (without azide).
• Buffer/Preservatives: 0.2 mg/ml in 1X PBS with 0.1 mg/ml rAlbumin (US sourced), 0.05% sodium azide
• Note: For research use only
• Application notes: Optimal dilution of the Vinculin antibody should be determined by the researcher.
• Expiration Date: 12 months from date of receipt.

Immunofluorescent staining of PFA-fixed human U-87 MG cells with Vinculin antibody (clone VCL/3617, green) and Reddot nuclear stain (red).

IHC staining of FFPE human testis with Vinculin antibody (clone VCL/3617). HIER: boil tissue sections in pH9 10mM Tris with 1mM EDTA for 20 min and allow to cool before testing.

IHC staining of FFPE human testis with Vinculin antibody (clone VCL/3617). HIER: boil tissue sections in pH9 10mM Tris with 1mM EDTA for 20 min and allow to cool before testing.

Flow cytometry testing of PFA-fixed human U-87 MG cells with Vinculin antibody (clone VCL/3617); Red=isotype control, Blue= Vinculin antibody.

Analysis of HuProt (TM) microarray containing more than 19000 full-length human proteins using Vinculin antibody (clone VCL/3617). These results demonstrate the foremost specificity of the VCL/3617 mAb. Z- and S- score: The Z-score represents the strength of a signal that an antibody (in combination with a fluorescently-tagged anti-IgG secondary Ab) produces when binding to a particular protein on the HuProt (TM) array. Z-scores are described in units of standard deviations (SD's) above the mean value of all signals generated on that array. If the targets on the HuProt (TM) are arranged in descending order of the Z-score, the S-score is the difference (also in units of SD's) between the Z-scores. The S-score therefore represents the relative target specificity of an Ab to its intended target.

SDS-PAGE analysis of purified, BSA-free Vinculin antibody as confirmation of integrity and purity.
